Forklift Starter and Alternator

Forklift Alternators and Starters - A starter motors today is normally a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid installed on it. Once current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is located on the driveshaft and meshes the pinion utilizing the starter ring gear which is found on the engine flywheel.

The solenoid closes the high-current contacts for the starter motor, which starts to turn. Once the engine starts, the key operated switch is opened and a spring in the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in just a single direction. Drive is transmitted in this way via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for example for the reason that the operator did not release the key when the engine starts or if the solenoid remains engaged because there is a short. This causes the pinion to spin independently of its driveshaft.

This above mentioned action stops the engine from driving the starter. This is actually an important step for the reason that this type of back drive will enable the starter to spin so fast that it could fly apart. Unless modifications were done, the sprag clutch arrangement will prevent the use of the starter as a generator if it was utilized in the hybrid scheme mentioned prior. Usually a standard starter motor is designed for intermittent use which would stop it being used as a generator.

The electrical parts are made to work for approximately 30 seconds to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical components are designed to save cost and weight. This is the reason nearly all owner's instruction manuals used for vehicles suggest the driver to stop for at least 10 seconds after each and every 10 or 15 seconds of cranking the engine, if trying to start an engine that does not turn over immediately.

In the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was used. The Bendix system works by placing the starter drive pinion on a helically cut driveshaft. As soon as the starter motor starts spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to go beyond the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

In the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design that was made and launched during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights in the body of the drive unit. This was better for the reason that the standard Bendix drive utilized so as to disengage from the ring once the engine fired, though it did not stay running.

Once the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement could be prevented prior to a successful engine start.
